Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link

China Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link supplier
Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link supplier Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link supplier Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link supplier Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link supplier Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link supplier

Large Image :  Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link

Product Details:

Place of Origin: Shenzhen China
Brand Name: lsailt
Certification: CE RoHS
Model Number: LLT-BZ-VER7.6.1

Payment & Shipping Terms:

Minimum Order Quantity: 10
Packaging Details: carton
Payment Terms: T/T, Western Union, PayPal
Supply Ability: 5000pieces/year
Contact Now
Detailed Product Description
Name Of Product: Android Navigation Box Installation Guide: Plug & Play Installation Under Dashboard
Car It Fit For: Peugeot SMEG+ & MRN System 208 308 508 3008 2008 Package Detail: 155*90*20 (MM)x2 Standard Export Carton
GR. WT: 2KG/SET System: Android 5.1
Optional Function: 360 Panorama TV DVR Parking Radar Etc Inside Storage Capacity: 16 GB

Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link



The Peugeot is the some brand of PSA car family, share the whole car platform and crucial technology with Citroen DS and other cooperate company, the design between Peugeot and Citroen is different but all of which shows the special French style, the interior look nice as well, the i-cockpit interior design, nicely control steering wheel and console.

About the inside system part, it's very same as their French rival Citroen and DS, only difference about them are the system UI. It's looks nice when it has born, but so far now after many years of evolvement of IT industry, the interface of Peugeot origin is actually so much old fashion.

But our Android system box & video interface for Peugeot & Citroen with MRN & SMEG+ really change anything in your mind, you can simply add the system inside the car without destroy anything, after all, with a much more opening system, you can install any application you like in Google play store into the car, like Google map, chrome, facebook, twitter, waze, youtube anything you can't imagine about a normal car! More over, the rearview, 360 degree panorama sight view, data video record, TPMS, GPS tracker, reversing radar etc, all these device can attach on the system as optional equipment.



Brand name: Lsailt    Model NO: LLT-BZ-VER7.6.1

Standard Configuration: Video Interface (Flexible parking guide line rear view, Front View, Video Input)and Android Navigation Box;

Suitable car model: 2013-2016 Peugeot 208,2008,308,408,508 (SMEG+ MRN SYSTEM)

Upgrading Function:Touch Android Navigation System,Trajectory Reversing,Front View,DVD,TV,360 Panoramic,DVR,TPMS etc.



Universal Product Information

Origin Shenzhen Trademark Lsailt
Product Model LLT-BZ-VER7.6.1 Standard CCC,CE
Type Android Video Interface Use Automotive





Custom Properties

Way to Install Original Car Screen Installation Advantage Retains All Features
RGB IN Support AV IN AV1 or AV2
DVR IN Support Rear View Support
Front View Support 360 Optional
CPU 1.6GHZ RAM 1GB/2GB
Flash 8GB and 16GB HD Video 720P/1080P
Working voltage 9-12V OS Android4.2.2/4.4.4
HVGA 800X480 MAP GOOGLE MAP/IGO
Play Store Support Voice Support
WIFI Support Specific Features One-Key Reset
BT Support MirrorLink Support



Product Description



1.Apply to:2013-2016 Peugeot 208,2008,308,408,508(SMEG+ MRN SYSTEM)

2.Supports external video input,full touch DVD,Android system;

3.Support trajectory reverse, Support front video input. You can choose to install 360 bird's eye view panoramic, truly achieve parking without blind area;

4.Optional external RGB (800 x480) input,Andrews system connection,HD display;

5.Multiple Switching ways:long press screen,double sliding,party control,etc;

6.Full-digital circuit, LVDS signal processing, achieve high-definition images;

7.Navigation voice optional (the original car/separate speakers).Input all voice into the original car audio system! Achieve perfect sound;

8.It’s convenient for drivers and passengers to enjoy different entertainment programs since the foreground-background work independently;

9.UI of the original car UI,matching the original car style,integrated the original car system;

10.Full pull-in installation,realize nondestructive installation;



Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link



Product Accessories
Interface box 1(standard configuration)
Android box 1(standard configuration)
LVDS IN 1(standard configuration)
LVDS OUT 1(standard configuration)
AV IN/OUT 1(standard configuration)
POWER Line 2(standard configuration)
GPS-ANT 1(standard configuration)
Microphone 1(standard configuration)
SPK 1(standard configuration)
Map card 1(standard configuration)
WIFI ANT 1(standard configuration)
Specification 1(standard configuration)
Warranty card 1(standard configuration)



Interface Parameter
Model LLT-BZ-VER7.6.1
Brand (Lsailt)
Car Screen Size 7 "
Type Silver interface box
Display LVDS/GVIF Signal transmission(The Board)
RGB Input One
AV Input Two
DVR Input One
Front View One
Rear View Track Reversing and Video
Customization Negotiated
General Parameters Andrews
CPU 1.6G Hz
Model Cortex A9 Four dual-core processor,car rule PX3
RAM DDR3 1GB/2GB
Flash Inand standard equipped,8GB or 16GB
Navigation Storage TF card
OS Android 4.2/4.4
HVGA 800X480
WIFI Support
BT support BT4.0
MirrorLink Android and OS The android support touch
Operating Voltage DC(9-15)V
Operating Current Normal 400 mA@12V
Operating Temperature -20°C—+70°C
Storage Temperature -30°C—+80°C
Audio Output Left and right channels,stereo,distribute the signal and analog output



Function Parameters Andrews
USB Function
USB Interface Two-way interface,can external connect a stern line of USB HUB,USB.
Connect external 3G Dongle(WCDMA/CDMA2000/TD-SCDMA)
Maximum:32GB,support FAT/NTFS hard disk,U flash disk;compatible USB1.0,USB2.0
Audio File Format MP3,M4A,WAV,AMR,AWB,AAC,FLAC,MID,MIDI,XMF,RTTTL,RTX,OTA,WMA,RA,MKA,M3U
Functions of Audio Media Select songs from list,play, pause,the last song, the next song,shuffle play,repeat playback,3 d effects ID3 display information of songs
Format of Video File MPG,MPEG,DAT,VOB,TS,TRP,TP,M2TS,MTS,MP4 ,MOV,RMVB,RM,MKV,DIVX,AVI,ASF,WMV,FLV,TS,WEBM.
Functions of Video Media Select video from list,Play, pause,the last one,the next one(Don’t support background)
Format of Picture File JPEG,JPG,GIF,PNG,BMP,WBMP
Functions of Picture Media Select pictures from list,Play,pause,the last picture,the next picture,Rotating pictures,set as wallpaper.
Internet
WIFI

After good Wi-Fi connection,select the current can be connected Wi-Fi hotspots,enter the password to connect to the Internet after the Internet

Via your 3G/4G mobile phone can also be used as hot provide navigation hosts (this set with reference to your mobile phone manual)

3G 3G/WCDMA/CDMA2000/TD-SCDMA standard
Support surf the Internet through 3G USB dongle or 3G mobile share next work
MAP (GPS Navigation)
Supportable navigation software Beauty line,DaoDaoTong,LingTu, hypergraph,NaviOne,AutoNavi,baidu,Google,IGO,SYGIC
Map Upgrading Through TF card
Support 3D live navigation,(Need navigation software to support)
Support navigation sound mixing/sound sent back
Support real-time traffic(Need navigation software to support,internet)
Support multiple navigation software


3G Dongle

NO. Type Network Format
1 HUAWEI E220 WCDMA
2 HUAWEI E182E WCDMA
3 HUAWEI E1550 WCDMA
4 HUAWEI E1750 WCDMA
5 HUAWEI E1756 WCDMA
6 HUAWEI E1762 WCDMA
7 HUAWEI E261 WCDMA
8 ZTE MF110 WCDMA
9 ZTE MF190 WCDMA
10 ZTE MF180 WCDMA
11 ZTE WCDMA
12 ZTE WCDMA
13 HUAWEI EC122 CDMA
14 HUAWEI EC156 CDMA
15 HUAWEI EC167 CDMA
16 HUAWEI EC189 CDMA
17 HUAWEI EC1261 CDMA
18 HUAWEI EC1270 CDMA
19 ZTE AC580 CDMA
20 ZTE AC582 CDMA
21 HUAWEI ET127 TD-SCDMA
22 HUAWEI ET128 TD-SCDMA
23 HUAWEI ET188 TD-SCDMA
24 ZTE A355 TD-SCDMA
25 ZTE A351+ TD-SCDMA
26 ZTE TD-SCDMA





Peugeot 208 2008 308 3008 508 Audio Video Interface SMEG+ MRN SYSTEM Upgrade WIFI BT Mirror Link

Upgrade System



There are many ways to upgrade:

1.The way without enter into system:

1)Write the update.img file to the SD card by SD Card Tool, make a boot disk. Insert the card and power on , system will copy to flash from SD card.

2) Put update. Img file into U disk, put down the sleep din before the 10S sleep in boot process . Upgrade system from U disk When have not detected SD.

3) If have not inserted the U disk and SD card which with update. img .Put down the sleep din before the 10S sleep in boot process ,the system will come into Recovery mode automatically .

Move into the Recovery mode.

2. After come into system , if insert the SD card or U disk which with update. Img , upgrade modal dialog box pops up, within the 5S No operating automatically enters upgrade mode.
