Payment & Shipping Terms:
|Classification:||Navigation Box||Suitable Model:||MERCEDES-BENZ A Class|
|Function:||GPS Car Navigation||Android System:||4.4 5.1|
|RAM:||1 / 2 GB||Flash:||8 / 16 GB|
|Navi App:||Google IGO PAPAGO||Extra Function:||Mirrorlink|
GPS Android navigation box interface box For BENZ C,CLA,CLK,B,A,E,GLC(NTG5.0)
Optional Touch Navigation,WIFI,BT, MirrorLink,HD 1080P,Google MAP, Play Store, Voice control, Android application
Not like it's predecessor pre 2011 A class, the new generation has becoming the real compact size hatchback with more sporty design and modify. And officially the A class own it's AMG version, the after facelift version A class has fit with new NTG 5.0 system, which is not that good to use as bigger brother S class.
Fortunately we have the solution, Xinsongxia is one of the leading manufacture of car video interface and Android navigation box in China, with our upgradition, the the original car screen can become the new works with completely new Android system include all Android application working, Google map, facebook, youtube, instagram, you can play video and music online or during the car drive. What's more, the 360 all view and reverse radar, data video record, tire pressure monitring system etc. If you don't like it you can switch back to Mercedes origin system with just one click.
Brand of manufacture: Lsailt Device Model: LLT-BENZ-VER2.2.1
Standard equip: Video Interface (guideline rearview, Front camera, Video signal Input) with Android Navigation Box;
Car model can be fit: 2015-2016 Mercedes-benz C, CLA, CLK, B, A, E, GLC (Car NTG-5.0 System)
Upgrading Function:Touch Android Navigation System,Trajectory Reversing,Front View,DVD,TV,360 Panoramic,DVR,TMPS etc.
Universal Product Information
|Type||Android Video Interface||Use||Automotive|
Features of Android system
Master processor: RK3188T Quad-Core Processor(RK 3188T/RK 3188/PX3)basic frequency 1.6GHz.
Memory capacity:1G DDRIII,2G DDRIII optional.
Flash memory: 8G EMMC Flash memory, with maximum 64G extention.
Operating system: Android 4.4.4.
GPS receive: support AGPS function
GPS antenna: 3V active antenna
GPS antenna protection: prevent the antenna short circuit
WiFi module: RTL8188/RTL8723.
Blurtooth module: RTL8723BU, with Bluetooth 4.0 support, firmware support Bluetooth functions.
Support USB 3G dongle,WiFi can be as a hot spot output.
Support USB camera which support DVR.
Synchronizing signal:composite synchronizing signal. Separate sync signal.
Audio: Left and right channel stereo output with audio valid indication signal.
Sound Control output: IO output or UART output.
Single track MIC input: support voice navigation, support SPDIF output.
Touchscreen interface:Support 4-wire resistive touch (support two point touch function), support serial touch, two ways to touch without modifying the hardware. Change software will be ok.
Video output signal: simulate RGB and CVBS composite synchronizing signal output , with one of them optional.
Analogue video output signal: Support the display position, brightness contrast adjustment.
The resolution of the video output: 800×480,1024X600,Maximum 1920X1080, any resolution supported.
Memory card spec: support maximum 64 gb TF/SD card, support read U disk, mobile hard disk storage.
USB port supported: USB 2.0, OTG available.
Supported map software:APK install automatically or installation package .
Voltage range: 7 ~ 16v (optional 9 ~ 28V), with undervoltage shutdown (7V protection shutdown).
ACC control: ACC support delay shutdown, and SLEEP combination can be set off at any time.
|General Parameters Andrews|
|Model||Cortex A9 Four dual-core processor,car rule PX3|
|Flash||Inand standard equipped,8GB or 16GB|
|Navigation Storage||TF card|
|MirrorLink & cast screen||Android and OS The android support touch|
|Operating Current||Normal 400 mA@12V|
|Audio Output||Left and right channels,stereo,distribute the signal and analog output|
After good Wi-Fi connection,select the current can be connected Wi-Fi hotspots,enter the password to connect to the Internet after the Internet
Via your 3G/4G mobile phone can also be used as hot provide navigation hosts (this set with reference to your mobile phone manual)
|Support surf the Internet through 3G USB dongle or 3G mobile share next work|
|MAP (GPS Navigation)|
|Supportable navigation software||Beauty line,DaoDaoTong,LingTu, hypergraph,NaviOne,AutoNavi,baidu,Google,IGO,SYGIC|
|Map Upgrading||Through TF card|
|Support 3D live navigation,(Need navigation software to support)|
|Support navigation sound mixing/sound sent back|
|Support real-time traffic(Need navigation software to support,internet)|
|Support multiple navigation software|
|Functions||Support to copy, move files between different storage medium and different folders|
|Support to delete files|
|Functions||Support the task list of activities|
|Support to switch the activities task|
|Support to close the activities task|
|System with Google||The browser,calculator,calendar and send E-mail,Google store|
|Software Upgrading||TF or U flash disk|
|System Language||Multi language|
Specifications of System
|Frequency||1575.42± 1 .023 MHz|
|Number of channels||66 channel|
|Tracking sensitivity||-1 61dBm|
|Positioning accuracy||3.0m CEP|
|Data update rate||1HZ|
|Hot start time||1S|
|Warm start time||32S|
|Cold start time||35S|
|Maximum positioning height||18000m|
|GPS Antenna||Active ceramic antenna|
|Antenna noise factor||<2dB|
|Antenna voltage||3V± 5%|
|Antenna current||1 5mA|
There are many ways to upgrade:
1.The way without enter into system:
1)Write the update.img file to the SD card by SD Card Tool, make a boot disk. Insert the card and power on , system will copy to flash from SD card.
2) Put update. Img file into U disk, put down the sleep din before the 10S sleep in boot process . Upgrade system from U disk When have not detected SD.
3) If have not inserted the U disk and SD card which with update. img .Put down the sleep din before the 10S sleep in boot process ,the system will come into Recovery mode automatically .
Move into the Recovery mode.
