Product Details:
|
| CPU: | 1GHZ | RAM: | 256MB |
|---|---|---|---|
| OS: | WINCE 6.0 | HVGA: | 800x480 |
| Working Voltage: | 9-12V | ||
| High Light: | gps car navigator,car gps navigation system |
||
JVC GPS Navigation Box Installes In-dash Monitors , Works with JVC Excelon without Cut Wirings, Navigation System
Products Descriptions
HD/Mimic Navigation Box works with JVC-KW-V10/V60/KW-AVX646/735/736/835/836/746/846/648/848
Nondestructive installation design, which does not damage to the wires of original car; special interface cable, plug-up installation without wire cut
After upgrading, it still remains all the functions of the original head unit, even if navigation goes wrong, which does not affect the function of the original car
After-sales service is convenient, replace the adapter module directly, compare with special machine, it’s much simpler, less risk, more safe and reliable
Achieve handwritten navigation, and control the navigation by touching it. Compare with the original navigation module, it’s more convenient and flexible
Product accessories | |
Mainframe | 1(standard configuration) |
Dedicated wire | 1(standard configuration) |
Antenna | 1(standard configuration) |
Specification | 1(standard configuration) |
certification | 1(standard configuration) |
Warranty card | 1(standard configuration) |
Microphone | 1(optional configuration) |
Speaker | 1(optional configuration) |
Map card | 1(optional configuration) |
Mute dedicated line | 1(optional configuration) |
Product parameters | |
Frequency: | 800MHZ/1GMHZ |
Main chip model: | MSB2531/Mstar785 |
Memory: | 256MB/512MB |
Storage space: | 128MB(can expand to 8GB) |
Navigation software storage: | SD/TF card |
Operating system: | WINCE6.0 CORE |
Support audio type | MP3/PCM/WMA etc. |
Support video type: | Mp4/mpeg/mpg/asf/wmv/mov etc. |
Video output format: | Composite Video(CVBS,Y/C,YPbPr)/ Analog RGB |
Video output voltage: | 1.0Vpp/75Ω |
Resolution: | 800X480(selection by resistor) |
Sound output: | Dual channel CD stereo sound |
Operating temperature: | ~40 to +85 |
Storage temperature: | ~40 to +100 |
Operating voltage: | DC 9-16V |
Tracking sensitivity: | ~161dBm |
Positioning accuracy: | 10m, 2D RMS,5m, 2D RMS, WAAS enable |
GPS Antenna type: | External active ceramic antenna |
Product Application
Super auto supplies supermarket,car audio modification store,automobile service factory
Applied to the car DVD host:PIONEER/KENWOOD//JVC/ALPINE/
Competitive Advantages:
1． Easy installation. Nondestructive installation；
2． Random installation ,without secondary installation；
3． Simple functions, strong stability, which more useful,
4． Convenient to upgrade map.
For models: 2015 Models:
AVH-X1750DVD,AVH-X2750BT,AVH-XL4750DVD,AVH-XL4750DVD,AVH-XL5750BT,AVH-X5750,AVH-X6750DVD,AVH-X7750BT,AVH-X8750BT
