Product Details:
|
Chip: | BCM4752 | Positioning Accuracy: | 3.0m CEP |
---|---|---|---|
CPU: | 1.2GHZ-1.6GHZ | Rear View: | Yes |
DVR: | Yes | Mirrorlink: | Yes |
Highlight: | multimedia video interface,car radio interface |
Multimedia Android Auto Interface for Porsche PCM 4.0 support Headrest Monitor display , Android / IOS Mirrorlink
Overview
Car Multimedia video interface serves to connect external video sources, such as navigation box, rear view camera, front view camera , 360 panorama , DVD player, TV tuner, etc. to the original car monitor.
This unit is designed for 2016-2017 Porsche Macan.
For Android navigation box:
Master processor :RK3188T Quad-Core Processor(RK 3188T/RK 3188/PX3),
Basic Frequency : 1.6G.
Memory capacity: 1G D D RIII , 2G DD RIII optional .
Flash memory: 8G E MMC Flash, maximum 64G .
OS: Android 4.4.4
GPS receive:support AGPS function
GPS antenna: 3V active antenna
GPS antenna protection : prevent the antenna short circuit
WiFi module : RTL8188/RTL8723.
WiFi module: RTL8723BU, support BT4.0, firmware support Bluetooth functions.
A2DP,Bluetooth telephone.
2 Video IN : For Rear View Camera and front view camera
2AV IN : For Digital TV and DVD
For Video Interface:
Output:
1 AV out for Headrest monitor ( you can also add an amplifier for it )
Power :
Working Voltage : 9-12V
Features :
● Support apps download
● Support worldwide IGO maps .
● support touch screen control
● Support Intelligent parking assist system (IPAS)
● Reverse camera auto trigger
● External speaker for navigation and original car speaker for multimedia
● Support USB HD 1080P multimedia playback
● Plug and play for easy installation
Specifications of Android System :
Chip | BCM4752 |
Frequency | 1575.42± 1 .023 MHz |
Number of channels | 66 channel |
Tracking sensitivity | -1 61dBm |
Positioning accuracy | 3.0m CEP |
Rate | 0.1 m/s |
Data update rate | 1HZ |
Re-capture time | <1S |
Hot start time | 1S |
Warm start time | 32S |
Cold start time | 35S |
Maximum positioning height | 18000m |
Maximum rate | 515m/s |
GPS Antenna | Active ceramic antenna |
Antenna gain | 27dB |
Antenna noise factor | <2dB |
VSWR | 1 .5 |
Antenna voltage | 3V± 5% |
Antenna current | 1 5mA |
