Product Details:
Place of Origin: Shenzhen China
Brand Name: Lsailt
Certification: CE, CCC
Model Number: LLT-BENZ-VER2.0.1
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Packaging Details: standard export carton
Delivery Time: 10 working days after receive payment
Payment Terms: T/T, Western Union, PayPal
Supply Ability: 2000 pieces/month

Mercedes benz E class Automobile GPS Navigation Systems video interface

Description
Classify: GPS Navigation Car Model: MERCEDES-BENZ E CLASS
Function: Video Interface CPU: Quad Core 1.6 GHz
RAM: 1 / 2 GB EMMC Storage: 8 / 16 GB
High Light:

car gps navigation system

,

gps navigation devices

Android video interface GPS navigation box​ For Mercedes-benz C, CLA, CLK, B, A, E, ML, GLK, GLA (NTG 4.5)

Optional Touch Navigation, WIFI, Bluetooth, Mirror Link, cast screen, HD 1080P, Google MAP, Play Store, Voice command,





Mecedes benz E class is highest luxury saloon beisde the S class and size is very similar with the S class, not like any other brother in Mercedes-benz family, E class could always equip with the latest techonlogy only after S class, but for the W212 generation, the NTG-4.5 car multimedia system is a main drawback, very rarely function compare with the Audi 3G MMI and BMW 2nd gen i-Drive, and very slowly running speed really makes people feel annoy, but here is our solution.



Lsailt Android navigation box with video interface specially for mercedes-benz with NTG-4.5 system, include E class W212, which can upgrade the origin car from just a single screen to full multimedia entertaining system include all Android application like google map, youtube, facebook, waze, iGO, instagram, everything you can imagine about Android device all can be running on the system, more, the mirror link and cast screen from smartphone is supported, optional list include rearview with guide line, front view, 360 degree full sight, data video record etc.


Product Description



1.Apply to: 2012-2014 MERCEDES BENZ -C,GLK,CLK,B,A,E,GLA (Car NTG 4.5 System)

2.Supports external video input,full touch DVD,Android system;

3.Multiple Switching ways:long press screen,double sliding,party control,etc;

4.Full-digital circuit, LVDS signal processing, achieve high-definition images;

5.Navigation voice optional (the original car/separate speakers).Input all voice into the original car audio system! Achieve perfect sound;

6.Support trajectory reverse, Support front video input. You can choose to install 360 bird's eye view panoramic, truly achieve parking without blind area;

7.It’s convenient for drivers and passengers to enjoy different entertainment programs since the foreground-background work independently;

8.Optional external RGB (800 x480) input, Android system connection, HD display;

9.UI of the original car UI,matching the original car style, integrated the original car system;

10.Full pull-in installation,realize nondestructive installation;



Android system hardware information



Master processor: RK3188T Quad-Core Processor(RK 3188T/RK 3188/PX3)basic frequency is 1.6G.

Memory capacity: 1G DDRIII,2G DDRIII optional.

Flash memory: 8G EMMC Flash, maximum 64G.

OS: Android 4.4.

GPS receive: support AGPS function

GPS antenna: 3V active antenna

GPS antenna protection: prevent the antenna short circuit

WiFi module: RTL8188/RTL8723.

BT module: RTL8723BU,support BT4.0, firmware support Bluetooth functions.

A2DP,Bluetooth telephone.

Support USB 3G dongle,WiFi can be as a hot spot output.

Support USB camera which support DVR.

Synchronizing signal:composite synchronizing signal. Separate sync signal.

Video output format:simulate RGB and CVBS composite synchronizing signal output , one of them optional.

Analog video output:Support the display position adjustment,and brightness contrast adjustment.

The resolution of the video output:800×480,1024X600,Maximum 1920X1080,Support any resolution.

Audio output:Left and right channel stereo output with audio valid indication signal.

Sound Control output:IO output or UART output.

Single track MIC input:support voice navigation, support SPDIF output.

Touchscreen interface:Support 4-wire resistive touch (support two point touch function), support serial touch, two ways to touch without modifying the hardware. Change software will be ok.

Memory card types:support maximum 64 gb TF/SD card, support read U disk, mobile hard disk storage.

USB port :USB OTG 2.0 .

Supported map software:APK install automatically or installation package .

Voltage range: 7 ~ 16v (optional 9 ~ 28V), with undervoltage shutdown (7V protection shutdown).

ACC control: ACC support delay shutdown, and SLEEP combination can be set off at any time.



Advantage for Upgrading



1.Nondestructive installation design, do not damage the original car lien, special interface wire, plug-up installation without wire cut;

2.Select installation function freely (handwritten navigation, BT, DVD, Reversing, 360 panoramic, automobile data recorder, TMPS, mobile Internet app etc).Make low-end surpass high-end, and make up the function defect of high-end car;

3.Technology is comparatively reliable; Do not involve in the original car agreement. Technology risks are fewer and safer comparatively;

4.Remain all functions of the original host after upgrading. If there are some wrong with navigation, it will not have influence on the original car function;

5.Convenient After-sale service; point-to-point reparation, do not involve in original car accessories, it is more simple, fewer risks, safer and more reliable than dedicated machine;

6.Real nondestructive installation of Original car type, remain all functions of the original host after upgrading and tackle the problem of the new “Three Parks of Policy” and 4S that do not support warranty;

7.Original car UI design, perfect match. Long presses touch screen or original car button to switch navigation pattern.



Function Parameters Andrews
USB Function
USB Interface Two-way interface,can external connect a stern line of USB HUB,USB.
Connect external 3G Dongle(WCDMA/CDMA2000/TD-SCDMA)
Maximum:32GB,support FAT/NTFS hard disk,U flash disk;compatible USB1.0,USB2.0
Audio File Format MP3,M4A,WAV,AMR,AWB,AAC,FLAC,MID,MIDI,XMF,RTTTL,RTX,OTA,WMA,RA,MKA,M3U
Functions of Audio Media Select songs from list,play, pause,the last song, the next song,shuffle play,repeat playback,3 d effects ID3 display information of songs
Format of Video File MPG,MPEG,DAT,VOB,TS,TRP,TP,M2TS,MTS,MP4 ,MOV,RMVB,RM,MKV,DIVX,AVI,ASF,WMV,FLV,TS,WEBM.
Functions of Video Media Select video from list,Play, pause,the last one,the next one(Don’t support background)
Format of Picture File JPEG,JPG,GIF,PNG,BMP,WBMP
Functions of Picture Media Select pictures from list,Play,pause,the last picture,the next picture,Rotating pictures,set as wallpaper.
Internet
WIFI

After good Wi-Fi connection,select the current can be connected Wi-Fi hotspots,enter the password to connect to the Internet after the Internet

Via your 3G/4G mobile phone can also be used as hot provide navigation hosts (this set with reference to your mobile phone manual)

3G 3G/WCDMA/CDMA2000/TD-SCDMA standard
Support surf the Internet through 3G USB dongle or 3G mobile share next work
MAP (GPS Navigation)
Supportable navigation software Beauty line,DaoDaoTong,LingTu, hypergraph,NaviOne,AutoNavi,baidu,Google,IGO,SYGIC
Map Upgrading Through TF card
Support 3D live navigation,(Need navigation software to support)
Support navigation sound mixing/sound sent back
Support real-time traffic(Need navigation software to support,internet)
Support multiple navigation software
File Manager
Functions Support to copy, move files between different storage medium and different folders
Support to delete files
Task Manager
Functions Support the task list of activities
Support to switch the activities task
Support to close the activities task
System with Google The browser,calculator,calendar and send E-mail,Google store
Software Upgrading TF or U flash disk
Voice Recognition Support
System Language Multi language

Specifications of System

CPU BCM4752
Frequency 1575.42± 1 .023 MHz
Number of channels 66 channel
Tracking sensitivity -1 61dBm
Positioning accuracy 3.0m CEP
Rate 0.1 m/s
Data update rate 1HZ
Re-capture time <1S
Hot start time 1S
Warm start time 32S
Cold start time 35S
Maximum positioning height 18000m
Maximum rate 515m/s
GPS Antenna Active ceramic antenna
Antenna gain 27dB
Antenna noise factor <2dB
VSWR 1 .5
Antenna voltage 3V± 5%
Antenna current 1 5mA

The maximum rated operating parameters table

Operating voltage 9-12V
Operating current 300mA
Maximum power consumption 2.5W
Shutdown current 1 mA
Off Power 30mW
Operating ambient temperature -10 ºC -- +80 ºC
Storage temperature -50 ºC -- +90 ºC

wireless specifications

Protocol standard IEEE 802.11b, IEEE 802.11g, IEEE 802.n
Frequency Range 2.400~2.4835GHz
Channels 1~11(the US,Canada),1~13(China,Europe),1~14(Japan)
Modulation mode 802.11b:DSSS (CCK, DQPSK, DBPSK)
802.11g/n:OFDM (BPSK, QPSK, 16QAM, 64QAM)
Speed ​​of wireless 802.11b 11, 5.5,2, 1Mbps
802.11g 54, 48, 36, 24, 18, 12, 9, 6Mbps
802.11n
Transmit power 802.11b 11Mbps:15±1.5dBm
802.11g 54Mbps:13 ±1.5dBm
802.11n 135Mbps:13 ±1.5dBm
Sensitivity 270M: -74dBm@10% PER
130M: -74dBm@10% PER
108M: -74dBm@10% PER
54M: -73dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -95dBm@8% PER
Working mode Peer to pee(Ad-Hoc)or Centralized control type(Infrastructure)
Operating voltage DC 3.3V ±0.2V
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission distance indoor 100 M,outdoor 300 M(depend on surroundings)
system WINXP/VISTA/LINUX/WINCE/WIN7
Operating temperature 0°C- 40°C
Operating Humidity 10% -90% RH condensing
Storage temperature -40ºC-70ºC;
Storage humidity 5%-90% RH Non-condensing.

3G Dongle

NO. Type Network Format
1 HUAWEI E220 WCDMA
2 HUAWEI E182E WCDMA
3 HUAWEI E1550 WCDMA
4 HUAWEI E1750 WCDMA
5 HUAWEI E1756 WCDMA
6 HUAWEI E1762 WCDMA
7 HUAWEI E261 WCDMA
8 ZTE MF110 WCDMA
9 ZTE MF190 WCDMA
10 ZTE MF180 WCDMA
11 ZTE WCDMA
12 ZTE WCDMA
13 HUAWEI EC122 CDMA
14 HUAWEI EC156 CDMA
15 HUAWEI EC167 CDMA
16 HUAWEI EC189 CDMA
17 HUAWEI EC1261 CDMA
18 HUAWEI EC1270 CDMA
19 ZTE AC580 CDMA
20 ZTE AC582 CDMA
21 HUAWEI ET127 TD-SCDMA
22 HUAWEI ET128 TD-SCDMA
23 HUAWEI ET188 TD-SCDMA
24 ZTE A355 TD-SCDMA
25 ZTE A351+ TD-SCDMA
26 ZTE TD-SCDMA



Mercedes benz E class Automobile GPS Navigation Systems video interface 0

Mercedes benz E class Automobile GPS Navigation Systems video interface 1Mercedes benz E class Automobile GPS Navigation Systems video interface 2

Upgrade System



There are many ways to upgrade:

1.The way without enter into system:

1)Write the update.img file to the SD card by SD Card Tool, make a boot disk. Insert the card and power on , system will copy to flash from SD card.

2) Put update. Img file into U disk, put down the sleep din before the 10S sleep in boot process . Upgrade system from U disk When have not detected SD.

3) If have not inserted the U disk and SD card which with update. img .Put down the sleep din before the 10S sleep in boot process ,the system will come into Recovery mode automatically .

Move into the Recovery mode.

  • After come into system , if insert the SD card or U disk which with update. Img , upgrade modal dialog box pops up, within the 5S No operating automatically enters upgrade mode.
