Lexus LS460 LS600h 2007-2009 mirror link video interface rear view 360 panoram

Car Android GPS Navigation System Video Interface box For Lexus LS460 LS600h between 2007 to 2009, other Lexus same year are also compatible;

Upgrade Touch Navigation Wi-Fi Bluetooth MirrorLink HD 1080P video & HQ music play Google MAP Play Store stream media waze Voice command,

For all Lexus between 2005 to 2009 include IS ES GS LS RX with Lexus factory screen and navigation system!

Note: only middle & high equip model Lexus LS with factory origin navigation could be compatible with our system.

Brand: Lsailt Model: LLT-LKSS-VER7.0.1

Standard Configuration: Video Interface (Rear view flexible guideline,Front View,Video Input)and Android Navigation Box;

Suitable car model: 2005-2009 Lexus LS460 LS600h etc IS ES GS RX

Upgrading Function:Touch Android Navigation System,Trajectory Reversing,Front View,DVD,TV,360 Panoramic,DVR,TMPS etc.

Android’s features:

1. Android 5.1 & 4.4 system, Quad core 1.6GHz Cortex-A9 chip, quickest running speed in market.

2. Compatible all Android apps include YouTube, Waze, Google map, iGO, Real-time & offline navigation etc, free download from Play store.

3. Compatible to car origin rear view & front view, DVR, 360 panorama, TV box, TPMS optional.

4. Connect via Wi-Fi Bluetooth USB.

5. Could be switch to origin system with just one click on dashboard or steering wheel.

6. Simple plug & play installation.

7. Multi languages are supported, include English Pусский Français Español Português Arabic Persian Japanese Korean Hebrew etc

Professional festures & hardware

1. Multi screen interactive display is supported, LVDS out put.

2. Accessories like rear view, 360 bird eye camera box, DVD, DVB-T TV box, DVR, mirror link, video play via USB.

3. Support 2 RGB & LVDS video signal input.

4. HD 1080P video play supprted.

5. Voice control navigation from both factory MIC or ours.

6. Display definition 480*800.

7. RK3188T/PX3 main processor, Quad core Cortex-A9 structure, much quicker than Allwinner T3 A7 model.

8. WiFi module: RTL8188 / RTL8723.

9. BT module: RTL8723BU, support BT4.0, firmware support Bluetooth functions.

10. Touchscreen interface: Support 4-wire resistive touch layer

Features of Android system & hardware part

Master processor:RK3188T Quad-Core Processor(RK 3188T/RK 3188/PX3)basic frequency is 1.6G.

Memory capacity:1G and 2G DDRIII for you to choose.

Flash memory: 16G EMMC Flash, maximum 64G.

OS:Android 4.4 5.1 for you to choose

GPS receive:support AGPS function

GPS antenna:3V active antenna

GPS antenna protection:prevent the antenna short circuit

WiFi module:RTL8188/RTL8723.

BT module:RTL8723BU,support BT4.0, firmware support Bluetooth functions.

A2DP,Bluetooth telephone.

Support USB 3G dongle,WiFi can be as a hot spot output.

Support USB camera which support DVR.

Synchronizing signal:composite synchronizing signal. Separate sync signal.

Video output format:simulate RGB and CVBS composite synchronizing signal output , one of them optional.

Analog video output:Support the display position adjustment,and brightness contrast adjustment.

The resolution of the video output:800×480,1024X600,Maximum 1920X1080,Support any resolution.

Audio output:Left and right channel stereo output with audio valid indication signal.

Sound Control output:IO output or UART output.

Single track MIC input:support voice navigation, support SPDIF output.

Touchscreen interface:Support 4-wire resistive touch (support two point touch function), support serial touch, two ways to touch without modifying the hardware. Change software will be ok.

Memory card types:support maximum 64 gb TF/SD card, support read U disk, mobile hard disk storage.

USB port :USB OTG 2.0 .

Supported map software:APK install automatically or installation package .

Voltage range: 7 ~ 16v (optional 9 ~ 28V), with undervoltage shutdown (7V protection shutdown).

ACC control: ACC support delay shutdown, and SLEEP combination can be set off at any time.
