Product Details:
|
| Products Type: | Android GPS Navigation Box | Suitable Car System: | Porsche PCM 4.0 System |
|---|---|---|---|
| The Car Can Be Fitted: | Porsche Macan Cayenne Panamera Etc | Hardware Part: | Quad Core 1.6 GHz 1GB RAM 16 GB ROM |
| Android System Supported: | 4.4 | Screen Resolution: | 480*800 Pixels |
| Delivery Time: | In 5 Days After Payment | Navigation Services: | IGO Google Map Waze Etc |
| High Light: | gps car navigator,gps navigation devices |
||
Car Android Navigation System Video Interface box For 2017 or later Porsche-Macan, Cayenne(Car PCM4.0 System), Upgrade Touch Navigation,WIFI, Bt, Mirrorlink, Google Map, rear view, voice control
Brand name: Lsailt
Model NO: LLT-BSJ-VER1.8.2
Standard Configuration: Video Interface (Trajectory Reversing, Front View, Video Input all optional)and Android Navigation Box;
Suitable car model: 2017 or later Porsche-Macan, Cayenne(Porsche with PCM4.0 System);
Upgrading optional Function: Touch Android Navigation System, guide line rear view, Front View, DVD play, TV, 360 Panorama sight view, DVR, TPMS etc.
Android’s features:
1. Android 4.4 system, Quad core 1.6GHz Cortex-A9 chip, quickest running speed in market.
2. Compatible all Android apps include YouTube, Waze, Google map, iGO, Real-time & offline navigation etc, free download from Play store.
3. Compatible to car origin rear view & front view, DVR, 360 panorama, TV box, TPMS optional.
4. Connect via Wi-Fi Bluetooth USB.
5. Could be switch to origin system with just one click on dashboard or steering wheel.
6. Simple plug & play installation.
7. Multi languages are supported, include English Pусский Français Español Português Arabic Persian Japanese Korean Hebrew etc
Professional festures & hardware
1. Multi screen interactive display is supported, LVDS out put.
2. Accessories like rear view, 360 bird eye camera box, DVD, DVB-T TV box, DVR, mirror link, video play via USB.
3. Support 2 RGB & LVDS video signal input.
4. HD 1080P video play supprted.
5. Voice control navigation from both factory MIC or ours.
6. Display definition 480*800.
7. RK3188T/PX3 main processor, Quad core Cortex-A9 structure, much quicker than Allwinner T3 A7 model.
8. WiFi module: RTL8188 / RTL8723.
9. BT module: RTL8723BU, support BT4.0, firmware support Bluetooth functions.
10. Touchscreen interface: Support 4-wire resistive touch layer
Hardware performance & Android system
Master processor:RK3188T Quad-Core Processor(RK 3188T/RK 3188/PX3)basic frequency is 1.6G.
Memory capacity:1G DDRIII, 2G DDRIII optional.
Flash memory:16G EMMC Flash, maximum 64G.
OS:Android 4.4
GPS receive:support AGPS function
GPS antenna:3V active antenna
GPS antenna protection:prevent the antenna short circuit
WiFi module:RTL8188/RTL8723.
BT module:RTL8723BU,support BT4.0, firmware support Bluetooth functions.
A2DP,Bluetooth telephone.
Support USB 3G dongle,WiFi can be as a hot spot output.
Support USB camera which support DVR.
Advantage for Upgrading
1.Free on installation design, do not damage the original car cables system, special interface wire, plug-up installation without wire cut;
2.Select installation function freely (handwritten navigation, BT, DVD, Reversing, 360 panoramic, automobile data recorder, TMPS, mobile Internet app etc).Make low-end surpass high-end, and make up the function defect of high-end car;
3.Reliable technology; no need to get involve in the original car agreement. Technology risks are fewer and safer comparatively;
4.Remain all functions of the original host after upgrading. If there are something wrong with navigation, it will not have influence on the original car function;
5.Convenient After-sale service; point-to-point reparation, do not involve in original car accessories, it is more simple, fewer risks, safer and more reliable than dedicated machine;
6.Real nondestructive installation of Original car type, remain all functions of the original host after upgrading and tackle the problem of the new “Three Parks of Policy” and 4S that do not support warranty;
7.Original car UI design, perfect match. Long presses touch screen or original car button to switch navigation pattern.
| USB extention | ||
| USB Interface | Two-way interface,can external connect a extra line of USB HUB,USB. | |
| Connect external 3G Dongle(WCDMA/CDMA2000/TD-SCDMA) | ||
| Maximum:32GB,support FAT/NTFS hard disk,U flash disk;compatible USB1.0,USB2.0 | ||
| Audio File Format | MP3,M4A,WAV,AMR,AWB,AAC,FLAC,MID,MIDI,XMF,RTTTL,RTX,OTA,WMA,RA,MKA,M3U | |
| Functions of Audio Media | Select songs from list,play, pause,the last song, the next song,shuffle play,repeat playback,3 d effects ID3 display information of songs | |
| Format of Video File | MPG,MPEG,DAT,VOB,TS,TRP,TP,M2TS,MTS,MP4 ,MOV,RMVB,RM,MKV,DIVX,AVI,ASF,WMV,FLV,TS,WEBM. | |
| Functions of Video Media | Select video from list,Play, pause,the last one,the next one(Don’t support background) | |
| Format of Picture File | JPEG,JPG,GIF,PNG,BMP,WBMP | |
| Functions of Picture Media | Select pictures from list,Play,pause,the last picture,the next picture,Rotating pictures,set as wallpaper. | |
| Internet | ||
| WIFI |
After good Wi-Fi connection,select the current can be connected Wi-Fi hotspots,enter the password to connect to the Internet after the Internet |
|
| 3G | 3G/WCDMA/CDMA2000/TD-SCDMA standard | |
| Support surf the Internet through 3G USB dongle or 3G mobile share next work | ||
| MAP (GPS Navigation) | ||
| Supportable navigation software | Beauty line,DaoDaoTong,LingTu, hypergraph,NaviOne,AutoNavi,baidu,Google,IGO,SYGIC | |
| Map Upgrading | Through TF card | |
| Support 3D live navigation,(Need navigation software to support) | ||
| Support navigation sound mixing/sound sent back | ||
| Support real-time traffic(Need navigation software to support,internet) | ||
| Support multiple navigation software | ||
| Explorler | ||
| Functions | Support to copy, move files between different storage medium and different folders | |
| Support to delete files | ||
| Task Manager | ||
| Functions | Support the task list of activities | |
| Support to switch the activities task | ||
| Support to close the activities task | ||
| System with Google | The browser,calculator,calendar and send E-mail,Google store | |
| Software Upgrading | TF or U flash disk | |
| Voice Recognition | Support | |
| System Language | Multi language | |
